◆注意技(ji)術性性能參數 Main technical parameters
|
設備規格 Model |
1立方雙槍電控噴砂機 |
2立方雙槍電控噴砂機 |
3萬立方6槍電控型管道專用噴砂機 |
|
研磨材料桶厚度 Abrasive drum diameter (mm) |
1000 |
1500 |
1500 |
|
高 Height(mm) |
1550 |
2000 |
2500 |
|
耐磨材料桶體積 Abrasive drum volume (m3) |
1.0 |
2.0 |
3.0 |
|
氣動閥門重壓 Pressure(bar) |
0.5-0.8Mpa |
0.5-0.8Mpa |
0.5-0.8Mpa |
|
噴槍用量 Spray gun quantity |
2 |
1-10 |
6 |
|
噴管尺寸 Nozzle diameter (mm) |
¢8-¢12 |
¢8-¢12 |
¢8-¢12 |
|
裝砂量 Outfit sand amount |
剛玉砂/1500kg; 鋼砂/2500kg |
剛玉砂/3000kg; 鋼砂/5000kg |
剛玉砂/4500kg; 鋼砂/7500kg |
|
供氣 Air source |
10-16m3/min |
6-40m3/min |
30-48m3/min |
|
轉化率 Efficiency (m2/h) |
40-60 |
20-200 |
120-250 |
◆類(lei)產品特殊(shu)性 Product features
1. 可活動運營(ying),功(gong)能表全,配合齊,運營(ying)單純不(bu)方便。
2. 一定(ding)應有壓解水汽源,就(jiu)能開始(shi)科學規范率的(de)表明消除及光飾噴砂治理。
3. 可可根據還要使用(yong)手控(kong)式(shi)或自動控(kong)制噴砂實際操作具體方法。
1. Mobile operation, complete functions, perfect facilities, and convenient operation.
2. As long as have compressed air source, can perform high efficiency of the surface cleaning and light act the role ofing sandblasting processing.
3. Can choose hand control or the electric control gush arenaceous operating mode according to need.
◆常用(yong)范(fan)圍圖 Applicable scope
可用作(zuo)魔幻類件的噴(pen)砂凈化處(chu)理(li)(如鋼架(jia)構、港口(kou)碼頭修造、鋼條、水(shui)器、集裝貨等(deng))清除垃圾(ji)工作(zuo)任務(wu),衣服服務(wu)業牛仔褲服掩蓋噴(pen)砂。
Application: apply to large workpieces piating (such as steel structure, ship building, steel plates, boiler, container, etc) clean up, jeans garment industry to modify sandblasting.
